Blue Diamond - Skid Steer Brush Cutter Direct Drive Open Front 72" Extreme Duty
Blue Diamond - Skid Steer Brush Cutter Direct Drive Open Front 72" Extreme Duty

Blue Diamond - Skid Steer Brush Cutter Direct Drive Open Front 72" Extreme Duty

$9,799.99 USD

All States Ag Parts
DE SOTO, IA
  • All of our new parts are aftermarket replacements. The use of original manufacturer's names and part numbers is for reference purposes only
  • Fits Skid Steer Loader Attachments Universal Parts(s) Brush & Rotary Cutters
  • Blue Diamond Skid Steer, Brush Cutter, Extreme Duty, Direct Drive, Open Front, 72"
  • The deck is thicker and uses above and under deck reinforcements in high stress areas
  • Also added are wear bars on the sides to give longer life if used in abrasive ground conditions
  • Solid 3/4" thick blade carrier
  • The heavily reinforced deck has many new features for strength and to make it easier to clean
  • The direct drive bearing carrier is now grease packed and can be greased from a zerk under the hood
  • Under the deck, instead of a spline shaft, it has a 13” x 1” flange with ten 3/4" bolts connecting the blade carrier
  • The purpose built hydraulic motor drives a 3.5” forged one piece drive spindle that is housed in 2 massive bearings
  • Has 4 double edged blades
  • Cuts up to 6" trees
  • The wire protection kit between the deck and the blade carrier keeps fence wire and vines away from the lower bearing seal and reduces down time from hidden debris
  • The 10” deck clearance and the raised back allow cut debris to escape and to easily avoid bunching under the deck
  • Requires only 16 GPMs
  • Bearing seal protection kit under the deck
  • New longer lasting stamped blades
  • Available in low or high flow
  • 3.5" (at bearing, 4" at seal) forged one piece spindle is the toughest in the industry
  • Grease filled drive dramatically improves bearing life and down time due to seal damage
  • Custom purpose built motor and relief block out last industry standard motors
  • External cross-port reliefs protect motor versus internal relief valves
  • Blue Diamond offers a two year warranty
  • Made in the U.S.A.
  • Item ships via freight carrier please call 1-866-609-1260 for a freight quote
  • All new, rebuilt and used tractor parts have a 1-year warranty
  • All States Ag Parts Item No. 159069

Sales Tax

Applicable sales tax will be charged.
Price $9,799.99 USD
Name Blue Diamond - Skid Steer Brush Cutter Direct Drive Open Front 72" Extreme Duty
Category Misc
Stock Number 159069
